| Product Code SWD x LWD x T x SW (mm) |
Material | SWD Short Way (mm) |
LWD Long Way (mm) |
T Thickness (mm) |
SW Strand Width (mm) |
Weight (kg/m2) |
Open Area (%) |
Width x Length (mm) |
Stock Code |
|---|---|---|---|---|---|---|---|---|---|
| 5.00 x 10.00 x 0.50 x 0,65 | Mild Steel | 5.00 | 10.00 | 0.50 | 0.65 | 1.000 | 75 | 1000x30.000 | DKP0510050610R |
| 5.00 x 10.00 x 1.00 x 1.20 | Mild Steel | 5.00 | 10.00 | 1.00 | 1.20 | 3.750 | 53 | 1000x2000 | DKP0510101210 |
| 5.00 x 10.00 x 1.00 x 1.20 | Aluminum | 5.00 | 10.00 | 1.00 | 1.20 | 1.300 | 53 | 1000x2000 | ALU0510101210 |
| 5.00 x 10.00 x 0,50 x 1.05 | Stainless Steel | 5.00 | 10.00 | 1.00 | 1.05 | 3.256 | 59 | 1000x2000 | PSL0510101010 |
| 5.00 x 10.00 x 0.50 x 1.20 | Aluminum | 5.00 | 10.00 | 0.50 | 1.20 | 0.650 | 52 | 1000x30.000 | ALU0510051210R |
| 5.00 x 10.00 x 0.50 x 1.20 | Aluminum | 5.00 | 10.00 | 0.50 | 1.20 | 0.650 | 52 | 1200x30.000 | ALU0510051212R |
| 5.00 x 10.00 x 1.00 x 1.20 | Aluminum | 5.00 | 10.00 | 1.00 | 1.20 | 1.300 | 52 | 1000x30.000 | ALU0510101210R |
| 5.00 x 10.00 x 1.00 x 1.20 | Aluminum | 5.00 | 10.00 | 1.00 | 1.20 | 1.300 | 52 | 1200x30.000 | ALU0510101212R |
