This product model, which has attracted great interest, has been produced for you using both aluminum and DKP materials. Except for their weights, their other technical specifications are the same. With a 60% open area, it is one of the most commonly used products in large-scale expanded metal meshes. Architects sometimes prefer this product for suspended ceilings as well. If you prefer less open area, you can take a look at the 'New York 115-15' and 'New York 115-20' models.
| Product Code SWD x LWD x T x SW (mm) |
Material | SWD Short Way (mm) |
LWD Long Way (mm) |
T Thickness (mm) |
SW Strand Width (mm) |
Weight (kg/m2) |
Open Area (%) |
|---|---|---|---|---|---|---|---|
| 50.00 x 115.00 x 1.50 x 10.00 | Mild Steel | 50.00 | 115.00 | 1.50 | 10.00 | 4.710 | 60 |
| 50.00 x 115.00 x 2.00 x 10.00 | Mild Steel | 50.00 | 115.00 | 2.00 | 10.00 | 6.280 | 60 |
| 50.00 x 115.00 x 2.00 x 10.00 | Aluminum | 50.00 | 115.00 | 2.00 | 10.00 | 2.184 | 60 |
| 50.00 x 115.00 x 3.00 x 10.00 | Aluminum | 50.00 | 115.00 | 3.00 | 10.00 | 3.276 | 60 |
